How to set Motor Forward, Reverse,Stop on FX3U-32M Mistubishi

Mar 13, 2023

How to set Motor Forward, Reverse,Stop on FX3U-32M Mistubishi。

Flow Path:

Confirm Control Demand-----Control Plan Design-----Draw circuit diagram------Draw T diagram------Improve Design Plan-----Simulation and debugging-----Installationg and debugging.

Task analyze
IN/OUT	SOFT COMPONETS	SYMBOLS OF COMPONENTS	components Name	Control funtion
Input	0	1	Button	Run forward function
	1	2	Button	Run Reverse
	2	2	Button	STOP
Output	0	1	Relay	FWD connect or cut Power
Output	1	2	Relay	REV connect or cut Power

Then we run GX-WORKS software.
